The 51.2V 100Ah LiFePO4 solar lithium battery offers efficient, long-lasting energy storage for solar systems. Equipped with an advanced Battery Management System (BMS), it ensures optimal performance and safety. Its compact, wall-mounted design saves space while providing reliable energy, making it an ideal choice for both residential and commercial applications.
Item No :
51.2-100Cell Configuration :
16S1POrder(MOQ) :
1PCSPayment :
TT / Alibaba / PaypalProduct Origin :
ChinaColor :
White / Black / CustomizationService :
7days for sampleShipping Port :
Shenzhen / Shanghai / Ningbo / GuangzhouLead Time :
15 days to 60days , it's up to the transportation methods.Weight :
40KGWall-Mounted 51.2V 100A LiFePO4 Battery with Advanced BMS
Designed for residential and commercial energy storage, this 51.2V 100Ah Wall-Mounted LiFePO4 Battery provides a reliable 5.12kWh energy solution. Unlike standard lithium batteries, our unit integrates Grade A Gotion High-Tech Cells (3.2V 102Ah), ensuring superior stability and a lifespan exceeding 6,000 cycles at 80% DOD.
Specifications
Whether for off-grid power backup or hybrid solar systems, its compact wall-mounted design saves space while delivering industrial-grade performance.
| Model | 51.2V100Ah |
| Rated Voltage | 51.2V |
| Nominal Capacity | 100Ah -102Ah |
| Charge Voltage | 40-58.4V |
| Discharge Voltage | 40-58.4V |
| Cell Configuration | 16S1P |
| Battery System Discharge Current (Standard) | 50A |
| Battery System Discharge Current (Max) | 100A |
| Peak Charge/Discharge Current(A) | 120(2S) |
| Communicaiton | CAN/RS-485/RS-232 |
| Working Temperature | 0℃~55℃ Charge , -10℃ ~55℃ Discharge |
| Shelf Temperature | 20℃~45℃ |
| Certification | CE/IEC/UL/UN38.3/MSDS |
| Design Life | 10 YEARS |
| Size(mm) | 445*355*225mm / Customization |
| Weight | 40kg |
| Cycle Life | >8000 |
Key Features & Benefits
Premium Core Technology: Built with Gotion 3.2V 102Ah LiFePO4 Prismatic Cells and a 16S1P configuration for maximum safety and thermal stability.
Intelligent BMS Protection: The built-in Smart Battery Management System monitors voltage, current, and temperature in real-time, preventing overcharging, over-discharging, and short circuits.
Wide Inverter Compatibility: Supports CAN/RS485/RS232 communication protocols. Seamlessly compatible with mainstream global inverter brands (see list below).
Long-Term Reliability: Engineered for a 10-year design life with a robust metal casing that fits perfectly in garages or utility rooms.
Scalable Energy: Supports parallel connection (up to 15 units) to expand capacity for larger energy demands.
Inverter Compatibility (Tested & Verified)
This battery is pre-programmed to communicate with the following inverter brands:
Application Scenarios
Home Energy Storage: Store excess solar power during the day to power your home at night.
Peak Shaving: Discharge battery power during peak tariff hours to reduce electricity bills.
Emergency Backup: Keep essential appliances (refrigerators, lights, Wi-Fi) running during grid outages.
Frequently Asked Questions (FAQ)
Q1: Is this battery compatible with my existing 48V inverter?
Yes, our 51.2V 100Ah battery works with most 48V hybrid and off-grid inverters. It supports CAN and RS485 communication specifically for brands like Victron, Deye, and Growatt.
Q2: What is the actual usable capacity of this battery?
The total capacity is 5.12kWh. We recommend a Depth of Discharge (DOD) of 80% to maximize cycle life, giving you approximately 4.1kWh of daily usable energy.
Q3: Can I expand my system later?
Absolutely. You can connect multiple units in parallel to increase your total energy storage capacity as your needs grow.
The 51.2V 100Ah LiFePO4 solar lithium battery offers efficient, long-lasting energy storage for solar systems. Equipped with an advanced Battery Management System (BMS), it ensures optimal performance and safety. Its compact, wall-mounted design saves space while providing reliable energy, making it an ideal choice for both residential and commercial applications.
Details
Model A: 5.12kWh Integrated System | Perfect for essential backup power, daily load shifting, and small home/solar setups. Model B: 10.24kWh Integrated System | Ideal for whole-home backup, maximizing solar self-consumption, and off-grid applications. Residential Energy Independence: Store solar energy for use day and night. Uninterrupted Home Backup: Keep lights, refrigeration, and internet on during grid outages. Off-Grid Living & Cabins: A complete, reliable power source for remote locations. Small Business & Office Backup: Ensure business continuity and protect sensitive equipment.
